High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

Beijing Ding Ding Future Technology Co.Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

Brand Name : BWITT

Model Number : 110/220-3KVAS

Certification : CE,UL

Place of Origin : CN

MOQ : 1 piece

Price : 1 USD/pc

Payment Terms : L/C,T/T

Supply Ability : 1000 pieces / month

Delivery Time : 6-8 weeks

Packaging Details : cartons

Part Number : BWT220/220-3KVAR

DC Input : 220Vdc

DC Input Range : 185—285vdc

Rated output Voltage : 220Vac

Frequency : 50Hz

Frequency Accuracy : <0.1%

Dielectric Strength : 2KVA,1 Min

Noise(1m) : <45dB

Relative Humidity : 0~90% ,without Condensation

Ambient Temperature For Operation : -10~50℃

Contact Now

High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

The redundant Parallel Connection inverter is an inversion device that Converters 220Vdc Power Supplied by DC Power Supply into 220Vac 50Hz Sinusoidal AC Power. it is Designed with Complete Isolation of input and Allows Hot Plugging and Parallel Connection redundancy. it is a product specially designed for users with high requirements for power supply reliability and maintainability



Product Form

Rated Power

3KVA/2.4KW

Dimension

19’’ 2 RU

W482*H88*D390mm

Input Parameters

DC Input

220Vdc

DC Input Range

185285vdc

Bypass Input Range

176~264Vac

Bypass Switchover time

8-12ms

AC Output

Rated output Voltage

220Vac

Frequency

50Hz

Load Adjustment Rate

<1%

Frequency Accuracy

<0.1%

Factor

3:1

PF

Peaking@89%

Waveform Distortion

Resistive full load <3%, Non Linear Full Load <5%

Dynamic Response

Voltage Transition Range <3%,Transition Response Recovery time 60ms(Load From 0~100)

Current Non- Uniformity under Parallel Connection

<3% Effective Value of Rated Current

Overload Capacity

Over Load Current<105%, Continuous Operation

Over Load Current105~125%, Shutdown after 10 min

Over Load Current 125~150%, Shutdown after 1 min

Over Load Current>150%, Shutdown in 20ms

Protection Function

Protection Against Opposite Connection of input, Input Under/over Voltage, Output Overload, Output Short Circuit, And Over Temp.

Communication

Communication Interface

Rs485 & Dry Contact ,SNMP optional

Ambient Environment

Dielectric Strength

2KVA,1 Min

Noise(1m)

<45dB

Ambient Temperature For Operation

-10~50

Ambient Temperature For Transport and Storage

-40~70

Relative Humidity

0~90% ,without Condensation

Relative altitude (M)

3000m, At 1500 ~3000 Output Derating 1% for each 100m of Altitude increase

Declaration of Conformity

LVD

EN IEC 62368-1:2020+A11:2020

EMC

EN 55032:2015+A11:2020

EN 55035:2017+A11:2020

EN IEC 61000-3-2:2019

EN61000-3-3:2013+A12019


High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR


High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR



High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVARHigh Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVARHigh Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR

High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR
High Frequency Pure Sine Wave Power Inverter 220/220V 19 Inch Rackmount BWT220/220-3KVAR
Solutions
We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service for Telecommunication Companies in and out of China. We have a competent team and a network of trusted Partners around the world.

FAQ :
1. How do you control the quality?
A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.

2. What is your minimum order quantity?
A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.

3. Can you introduce your company?
A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.

4. What are the advantages of your company?
A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.

5. Can i send samples?Report it to me along with the price?
A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.

6. How do your company deal with the problem on quality?
A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.

7 What about the quality ?
A:100% original with new package. we will test each item before posted to make sure each item with good quality.

8 How many months for guarantee ?
A: 1 year quality guarantee

9 How to deal with any inferior -quality goods ?
A: Goods can be post by with our charge of post fee for any bad quality products within guarantee time.
